Car Wiring Diagrams for Cooling fan circuit for Audi RS Q8 I (2019-2024)

3.0L TURBO HYBRID 4.0L TURBO HYBRID A/C CLUTCH A/C COMPRESSOR (LEFT FRONT OF ENGINE) AFTER-RUN COOLANT PUMP BLK WIRE BLK/GRN WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM ENGINE COOLANT LEVEL SENSOR ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON ENGINE ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE PRE-WIRING COUPLING POINT 2 ENGINE/MOTOR CONTROL MODULE FUSE 13 FUSE 14 FUSE 3 FUSE 8 FUSE PANEL A GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/VIO WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED N/A ORG/BRN WIRE ORG/WHT WIRE OUTSIDE AIR TEMPERATURE SENSOR RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE RADIATOR FAN SECOND SPEED FUSE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE REGULATOR VALVE TOP OF ENGINE) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/YEL WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE YEL/VIO WIRE
