Audi RS Q8 I (2019-2024) wireless data transfer antenna 2 Wiring diagram
This page shows the only wiring diagram for the component.wireless data transfer antenna 2, which is found in the car Audi RS Q8 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wireless data transfer antenna 2 (1 of 1)
BLK WIRE
BLUETOOTH ANTENNA
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE ANTENNA
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE ANTENNA 3
EMERGENCY CALL MODULE SPEAKER
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FRONT ROOF MODULE (OVERHEAD CONSOLE)
FUSE 10
FUSE 8
FUSE PANEL B
FUSE PANEL E
GPS ANTENNA
GRN WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT MICROPHONE
MICROPHONE UNIT
NCA WIRE
ORG/BRN WIRE
PNK WIRE
RED/BLK WIRE
RED/VIO WIRE
RIGHT FRONT MICROPHONE
RIGHT REAR FOOTWELL
ROAD SIDE ASSISTANCE BUTTON
ROOF ANTENNA (REAR OF VEHICLE ROOF)
VIO/RED WIRE
WHT WIRE
WIRELESS DATA TRANSFER ANTENNA
WIRELESS DATA TRANSFER ANTENNA 2
YEL/VIO WIRE
Go to component -> Emergency call circuit, w/ connect plus -> WIRELESS DATA TRANSFER ANTENNA 2
