Audi RS Q8 I (2019-2024) right front reading lamp Wiring diagram
This page shows the only wiring diagram for the component.right front reading lamp, which is found in the car Audi RS Q8 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front reading lamp (1 of 1)
AUTOMATIC INTERIOR LIGHT SWITCH BUTTON
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/GRY WIRE
EMERGENCY CALL BUTTON
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FRONT PASSENGER EXTERIOR DOOR HANDLE ILLUMINATION LAMP
FRONT PASSENGER SEAT COUPLING POINT
FRONT ROOF MODULE (OVERHEAD CONSOLE)
FUSE 14
FUSE 8
FUSE PANEL E
GARAGE DOOR OPENER CONTROL MODULE
GRN WIRE
GRN/BRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
INTERIOR REAR VIEW MIRROR
LEFT FRONT READING LAMP
LEFT FRONT READING LAMP BUTTON
LEFT REAR READING LAMP
LEFT REAR READING LAMP SWITCH
REAR READING LAMP FRONT BUTTON
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT READING LAMP
RIGHT FRONT READING LAMP BUTTON
RIGHT REAR FOOTWELL LAMP
RIGHT REAR READING LAMP
RIGHT REAR READING LAMP SWITCH
ROAD SIDE ASSISTANCE BUTTON
ROOF ELECTRONICS CONTROL MODULE
ROOF SHADE BUTTON 1
SUNROOF BUTTON
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
Go to component -> Courtesy lamps circuit (2 of 6) -> RIGHT FRONT READING LAMP
