Audi RS Q8 I (2019-2024) left rear seat backrest temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear seat backrest temperature sensor, which is found in the car Audi RS Q8 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear seat backrest temperature sensor (1 of 1)
BLK/GRN WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE REAR SEAT TEMPERATURE SENSOR
FUSE 7
FUSE PANEL G
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT
LEFT REAR SEAT BACKREST TEMPERATURE SENSOR
LEFT REAR SEAT COUPLING POINT
PASSENGER SIDE REAR SEAT TEMPERATURE SENSOR
REAR A/C DISPLAY CONTROL HEAD
RED WIRE
RED/VIO WIRE
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR BENCH SEAT HEATING ELEMENT
RIGHT REAR FOOTWELL
RIGHT REAR SEAT BACKREST TEMPERATURE SENSOR
RIGHT REAR SEAT COUPLING POINT
VIO WIRE
VIO/WHT WIRE
W/ MULTI-ZONE CONTROLS
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Rear heated seats circuit -> LEFT REAR SEAT BACKREST TEMPERATURE SENSOR
