Audi RS Q8 I (2019-2024) left rear door coupling point Wiring diagrams

AUTOMATIC TRANSMISSION COUPLING POINT BLU WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE BRN/YEL WIRE COOLANT SHUT-OFF VALVE COUPLING POINT IN RIGHT REAR SEAT COUPLING POINT IN THE LEFT REAR DOOR COUPLING SECTION IN LEFT FRONT SEAT DATA BUS ON BOARD DIAGNOSTIC INTERFACE DECOUPLER ACTUATOR DRIVER ASSISTANCE SYSTEM CONTROL MODULE DRIVER SEAT ADJUSTMENT CONTROL MODULE DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT BOLSTER HEATER DRIVER SEAT COUPLING POINT DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SIDE HEATED SEAT DRIVER SIDE REAR DOOR CLOSING AID MOTOR DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR DOOR LOCK UNIT DRIVER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP DRIVER SIDE REAR SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP DRIVER THORAX AIR BAG IGNITER HEATED DRIVER SEAT EXTENSION LEFT FRONT SEAT BACKREST FAN 1 LEFT FRONT SEAT BELT LEFT FRONT SEAT CUSHION FAN 1 LEFT FRONT SEAT HEATED BACKREST LEFT REAR AIR VENT ILLUMINATION BULB LEFT REAR DOOR AMBIENT LIGHTING BULB 1 LEFT REAR DOOR CONTOUR ILLUMINATION LAMP LEFT REAR DOOR COUPLING POINT LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR LEFT REAR FOOTWELL LAMP MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR SEAT COUPLING POINT TRANSMISSION CONTROL MODULE W/ AMBIENT LIGHTING WHT/BRN WIRE

BLK/BLU WIRE BLK/GRN WIRE BLU/BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM FUSE GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT DOOR SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT SPEAKER LEFT FRONT TREBLE SPEAKER LEFT FRONT TREBLE SPEAKER, MOTOR LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR DOOR SPEAKER LEFT REAR MIDRANGE SPEAKER PNK WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT DOOR SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT FRONT TREBLE SPEAKER, MOTOR RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR DOOR SPEAKER RIGHT REAR MIDRANGE SPEAKER SUBWOOFER VIO/BLU WIRE VIO/BRN WIRE VIO/RED WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

BLK/BLU WIRE BLK/YEL WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM FUSE FUSE PANEL H GRN WIRE GRY WIRE GRY/BLK WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT "C" PILLAR) LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT DOOR SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER 2 LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR TREBLE SPEAKER PNK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RELAY & FUSE PANEL 3 RIGHT EFFECTS SPEAKER RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT DOOR SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER +2 RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR TREBLE SPEAKER VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE

BLK/BLU WIRE BLK/RED WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL CENTER SPEAKER COMPUTER DATA LINES SYSTEM DRIVER VOLUME CONTROL FUSE 13 FUSE 14 FUSE PANEL F GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT ORG/BRN WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR FOOTWELL RIGHT REAR TREBLE SPEAKER SOUND SYSTEMS VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE
