Audi RS Q8 I (2019-2024) left multi-function steering wheel Wiring diagram
This page shows the only wiring diagram for the component.left multi-function steering wheel, which is found in the car Audi RS Q8 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left multi-function steering wheel (1 of 1)
4-PIN CONNECTOR
BLK WIRE
BRN WIRE
FUSE 12
FUSE PANEL F
GRY WIRE
HEATED STEERING WHEEL
HEATED STEERING WHEEL SENSOR
HOT AT ALL TIMES
LEFT MULTI-FUNCTION STEERING WHEEL
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
RED WIRE
RED/GRY WIRE
SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL HEATING BUTTON
STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
VIO WIRE
Go to component -> Heated steering wheel circuit -> LEFT MULTI-FUNCTION STEERING WHEEL
