Audi RS Q8 I (2019-2024) left front seat backrest temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.left front seat backrest temperature sensor, which is found in the car Audi RS Q8 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front seat backrest temperature sensor (1 of 1)
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COUPLING STATION IN LEFT FRONT SEAT
COUPLING STATION IN RIGHT FRONT SEAT
DRIVER SEAT BOLSTER HEATER
DRIVER SEAT COUPLING POINT
DRIVER SEAT HEATING ELEMENT
DRIVER SIDE HEATED SEAT
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT PASSENGER SEAT BOLSTER HEATER
FRONT PASSENGER SEAT COUPLING POINT
FRONT PASSENGER SEAT HEATING ELEMENT
FUSE 1
FUSE PANEL C
GRN WIRE
GRN/BRN WIRE
HEATED DRIVER SEAT EXTENSION
HEATED FRONT PASSENGER SEAT EXTENSION
HOT AT ALL TIMES
LEFT FRONT SEAT BACKREST TEMPERATURE SENSOR
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT TEMPERATURE SENSOR
LEFT SEAT HEATING BUTTON
ORG/BRN WIRE
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT HEATED BACKREST
RIGHT FRONT SEAT TEMPERATURE SENSOR
RIGHT SEAT HEATING BUTTON
SENSOR TEMPERATURE BACKREST RIGHT FRONT SEAT
SUPPLEMENTAL RESTRAINTS SYSTEM
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT/BLU WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component -> Front heated seats circuit -> LEFT FRONT SEAT BACKREST TEMPERATURE SENSOR
