Audi RS Q8 I (2019-2024) front passenger lumbar support height adjustment sensor Wiring diagram
This page shows the only wiring diagram for the component.front passenger lumbar support height adjustment sensor, which is found in the car Audi RS Q8 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger lumbar support height adjustment sensor (1 of 1)
BLK WIRE
BLU/BRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER LUMBAR SUPPORT FORWARD/BACK ADJUSTMENT SENSOR
FRONT PASSENGER LUMBAR SUPPORT HEIGHT ADJUSTMENT SENSOR
FRONT PASSENGER SEAT LUMBAR SUPPORT
FRONT PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
FRONT PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER SEAT MEMORY BUTTON
FRONT PASSENGER SEAT MEMORY SETTINGS CONTROL HEAD
FRONT PASSENGER SIDE MEMORY SEAT INDICATOR LAMP
FUSE 14
FUSE PANEL E
GRN WIRE
GRY WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
MEMORY SEAT POSITION 1 BUTTON
MEMORY SEAT POSITION 2 BUTTON
ORG/BRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Passenger"s memory seat circuit, w/ sport seats (2 of 2) -> FRONT PASSENGER LUMBAR SUPPORT HEIGHT ADJUSTMENT SENSOR
