Audi RS Q8 I (2019-2024) engine temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.engine temperature sensor, which is found in the car Audi RS Q8 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine temperature sensor (1 of 1)
BANK 2 RECIRCULATION VALVE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
ENGINE COVER TEMPERATURE SENSOR
ENGINE TEMPERATURE SENSOR
FUSE 9
FUSE PANEL F
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BRN WIRE
HEATER OXYGEN SENSOR 2
HOT AT ALL TIMES
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
OIL PRESSURE REGULATION VALVE
OIL PRESSURE SWITCH
OIL TEMPERATURE SENSOR
OXYGEN SENSOR 2 BEFORE CATALYTIC CONVERTER
OXYGEN SENSOR 2 HEATER
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
WHT/GRN WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 4.0l turbo hybrid (7 of 12) -> ENGINE TEMPERATURE SENSOR
