Audi RS Q8 I (2019-2024) close range communication control module 2 Wiring diagram
This page shows the only wiring diagram for the component.close range communication control module 2, which is found in the car Audi RS Q8 I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram close range communication control module 2 (1 of 1)
ACCESS/START AUTHORIZATION BUTTON
AUXILIARY HEATER CONTROL MODULE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER COUPLING POINT IN INTERIOR
CENTER COUPLING POINT ON INSTRUMENT PANEL
CLOSE RANGE COMMUNICATION CONTROL MODULE 2
COUPLING POINT IN LEFT REAR SEAT
DIFFERENTIAL LOCK CONTROL MODULE
DIGITAL SOUND SYSTEM CONTROL MODULE
DRIVER VOLUME CONTROL
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
EXHAUST DOOR CONTROL UNIT
LEFT "C" PILLAR)
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT
LEFT REAR SEAT COUPLING POINT
LEFT REAR SEAT COUPLING STATION
LEFT REAR UPPER BODY VENT POSITION SENSOR
LEVEL CONTROL SYSTEM COMPRESSOR ELECTRONICS
MOBILE DEVICE CHARGER 1
PARKING BRAKE BUTTON
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
REAR A/C DISPLAY CONTROL HEAD
REAR CENTER AIR VENT ILLUMINATION BULB
REAR FRESH AIR BLOWER CONTROL MODULE
REDUCING AGENT METERING SYSTEM CONTROL MODULE
RIGHT REAR FOOTWELL
SELECTOR LEVER
SWAY STABILIZATION CONTROL MODULE 2
USB CONNECTION 1
USB DISTRIBUTOR
W/ MULTI-ZONE CONTROLS
Go to component -> Ground distribution circuit (7 of 7) -> CLOSE RANGE COMMUNICATION CONTROL MODULE 2
