Audi Q8 I facelift (2023-2024) A/t circuit

3.0L TURBO HYBRID 4.0L TURBO HYBRID ACCUMULATOR SOLENOID AUTOMATIC TRANSMISSION CONTROL MODULE FUSE AUTOMATIC TRANSMISSION COUPLING POINT AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 5 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 6 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 7 BLU/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM ENGINE/MOTOR CONTROL MODULE FUSE 4 FUSE 6 FUSE PANEL D FUSE PANEL E FUSE PANEL G GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/WHT WIRE PARKING LOCK SENSOR PARKING LOCK SOLENOID PNK WIRE RED WIRE RED/GRN WIRE RELAY & FUSE PANEL 2 SOLENOID VALVE 1 SUPPLEMENTAL RESTRAINTS SYSTEM TEMPERATURE SENSOR (IN CONTROL MODULE) TOP OF TRANSMISSION) TRANSMISSION CONTROL MODULE TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 1 TRANSMISSION FLUID COOLING VALVE TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION INPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR

4-PIN CONNECTOR BRN WIRE CENTER CONSOLE COMPUTER DATA LINES SYSTEM D/S FUSE 16 FUSE PANEL F GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE LEFT MULTI-FUNCTION BUTTONS STEERING WHEEL NCA WIRE ORG/BRN WIRE ORG/GRY WIRE PARKING LOCK IND LAMP PNK WIRE RED WIRE RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL RIGHT REAR FOOTWELL SELECTOR LEVER SELECTOR LEVER POSITION SENSOR SELECTOR LEVER RELEASE BUTTON, PARKING LOCK BUTTON SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER TRANSMISSION RANGE DISPLAY SHIFT LOCK SOLENOID SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON TRANSVERSE SELECTOR LEVER LOCK MOTOR TRANSVERSE SELECTOR LEVER LOCK SENSOR VIO WIRE
