Radio circuit, w/o amplifier for Audi Q8 I facelift (2023-2024)

BLK/BLU WIRE BLK/RED WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL CENTER SPEAKER COMPUTER DATA LINES SYSTEM DRIVER VOLUME CONTROL FUSE 13 FUSE 14 FUSE PANEL F GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT ORG/BRN WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT TREBLE SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR FOOTWELL RIGHT REAR TREBLE SPEAKER SOUND SYSTEMS VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE

ANDROID OPERATING SYSTEM CONTROL MODULE ANTENNA BLK WIRE BLU WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/VIO WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL FUSE 2 FUSE PANEL F GRN WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 NCA WIRE ORG/ WIRE RADIO ANTENNA 2 RED/BLK WIRE RED/VIO WIRE SUBWOOFER W/O TV TUNER

ACCESS/START AUTHORIZATION BUTTON BLK WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER COMPUTER DATA LINES SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE DATA LINES EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FUSE 15 FUSE 7 FUSE PANEL D FUSE PANEL J GRN WIRE GRY/RED WIRE HOT AT ALL TIMES NCA WIRE ORG/ WIRE ORG/BRN WIRE PNK WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RIGHT REAR FOOTWELL ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA SYSTEM USB CONNECTION 1 USB DISTRIBUTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE WHT WIRE

BLK WIRE BLU WIRE BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM FRONT INFORMATION DISPLAY CONTROL HEAD FRONT INFORMATION DISPLAY CONTROL HEAD 2 FUSE 5 FUSE 8 FUSE 9 FUSE PANEL F GRN WIRE GRY/RED WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE MOST DATA BUS CIRCUIT NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT) NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRY WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE SOUND SYSTEMS W/ FPK ACTIVE INFO DISPLAY W/O FPK ACTIVE INFO DISPLAY WHT WIRE
