Automatic a/c circuit, w/ climatronic w/o multi-zone controls & rear controls for Audi Q8 I facelift (2023-2024)

AUXILIARY HEATER CONTROL MODULE AUXILIARY HEATER HEATING ELEMENT BLK/BRN WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM DEFROSTER DOOR MOTOR FRESH AIR DOOR MOTOR FUSE 1 FUSE 10 FUSE 12 FUSE PANEL C FUSE PANEL D FUSE PANEL E GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HUMIDITY SENSOR INSTRUMENT PANEL TEMPERATURE SENSOR INTERIOR REAR VIEW MIRROR LEFT CENTER VENT MOTOR LEFT FRONT UPPER BODY VENT TEMPERATURE SENSOR LEFT TEMPERATURE CONTROL DOOR MOTOR LIGHT RECOGNITION SENSOR ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRY WIRE ORG/WHT WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR REAR AIR DISTRIBUTION DOOR MOTOR REAR TEMPERATURE CONTROL DOOR MOTOR RECIRCULATION DOOR MOTOR RED WIRE RED/GRY WIRE RED/YEL WIRE RIGHT CENTER VENT MOTOR RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR RIGHT TEMPERATURE CONTROL DOOR MOTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE WIRE JUNCTION 2 WIRE JUNCTION 2 FUSE 1 YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

A/C CLUTCH AIR QUALITY SENSOR BLK/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE BRN/BLU WIRE ENGINE COOLANT LEVEL SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET EVAPORATOR VENT TEMPERATURE SENSOR FRESH AIR BLOWER FRESH AIR BLOWER CONTROL MODULE FUSE 8 FUSE PANEL B GRN/BLU WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HIGH PRESSURE SENSOR HOT AT ALL TIMES INSTRUMENT CLUSTER SYSTEM LEFT FOOTWELL VENT TEMPERATURE SENSOR OUTSIDE AIR TEMPERATURE SENSOR RED/BLU WIRE REGULATOR VALVE RIGHT FOOTWELL VENT TEMPERATURE SENSOR VIO/WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL/VIO WIRE

3.0L TURBO HYBRID 4.0L TURBO HYBRID AFTER-RUN COOLANT PUMP BLK WIRE BLK/GRN WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DISPLAY UNIT ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON ENGINE ENGINE PRE-WIRING COUPLING POINT 2 ENGINE/MOTOR CONTROL MODULE FUSE 13 FUSE 14 FUSE 3 FUSE 8 FUSE PANEL A GRN/BLU WIRE GRN/GRY WIRE GRN/VIO WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE N/A ORG/BRN WIRE ORG/GRY WIRE ORG/WHT WIRE RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE RADIATOR FAN SECOND SPEED FUSE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE TOP OF ENGINE) VIO/YEL WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/VIO WIRE
