Emergency call circuit, w/o connect plus for Audi Q8 I (2018-2023)
Emergency call circuit, w/o connect plus
BLK WIRE
BRN WIRE
BRN/BLK WIRE
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE ANTENNA
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE SPEAKER
FRONT ROOF MODULE (OVERHEAD CONSOLE)
FUSE 7
FUSE 8
FUSE PANEL E
GPS ANTENNA SPLITTER (RIGHT "B" PILLAR)
GRN WIRE
HOT AT ALL TIMES
NCA WIRE
RED/BLK WIRE
RED/BLU WIRE
ROAD SIDE ASSISTANCE BUTTON
ROOF ANTENNA (REAR OF VEHICLE ROOF)
VIO/RED WIRE
W/ VEHICLE POSITIONING SYSTEM
