Computer data lines circuit for Audi Q8 I (2018-2023)

BLK WIRE BLU/GRN WIRE BOTTOM CENTER COUPLING POINT IN INTERIOR BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL DATA BUS ON BOARD DIAGNOSTIC INTERFACE (UNDER LEFT FRONT SEAT) DIAGNOSTIC CONNECTION DIFFERENTIAL LOCK CONTROL MODULE FUSE 1 FUSE 12 FUSE 2 FUSE 7 FUSE PANEL D FUSE PANEL E GRN WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE ORG/GRY WIRE PNK WIRE REAR AXLE STEERING CONTROL MODULE RED WIRE RED/BLU WIRE RED/YEL WIRE SELECTOR LEVER VIO WIRE VIO/BRN WIRE VIO/WHT WIRE VIO/YEL WIRE W/ REAR AXLE STEERING W/O REAR AXLE STEERING WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE YEL/BLU WIRE

ABS CONTROL MODULE ADAPTIVE CRUISE CONTROL MODULE ANTI-THEFT ALARM SYSTEM SENSOR BATTERY MONITORING CONTROL MODULE CENTER CONSOLE CENTER COUPLING POINT ON INSTRUMENT PANEL COMFORT SYSTEM CENTRAL CONTROL MODULE COUPLING POINT ON LEFT FRONT BUMPER DRIVER'S DOOR HANDLE ENGINE/MOTOR CONTROL MODULE GENERATOR, VOLTAGE REGULATOR GRN WIRE GRY/RED WIRE LASER DISTANCE REGULATION CONTROL MODULE LEFT FRONT DOOR COUPLING POINT NEAR FIELD COMMUNICATION CONTROL MODULE NEAR FIELD COMMUNICATION CONTROL MODULE 2 ORG/BRN WIRE ORG/GRY WIRE OVERHEAD CONSOLE PNK WIRE REAR LID CONTROL MODULE RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT TOWING RECOGNITION CONTROL MODULE VIO WIRE VIO/BLU WIRE VIO/WHT WIRE VIO/YEL WIRE W/ ADAPTIVE CRUISE CONTROL W/O ADAPTIVE CRUISE CONTROL WINDSHIELD DEFOGGER CONTROL MODULE

BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM LEFT COUPLING POINT ON ENGINE COUPLING POINT ON LEFT FRONT BUMPER DRIVER DOOR CONTROL MODULE DRIVER SEAT BACKREST BLOWER FAN DRIVER SEAT COUPLING POINT DRIVER SEAT CUSHION BLOWER FAN ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER MEMORY SEAT CONTROL MODULE FRONT PASSENGER SEAT BACKREST BLOWER FAN FRONT PASSENGER SEAT COUPLING POINT FRONT PASSENGER SEAT CUSHION BLOWER FAN GRN WIRE GRY/RED WIRE LEFT FRONT DOOR COUPLING POINT LEFT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE PNK WIRE POWER STEERING CONTROL MODULE RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT OBJECT DETECTION RADAR SENSOR CONTROL MODULE SUNROOF CONTROL MODULE TRANSMISSION CONTROL MODULE VIO WIRE VIO/WHT WIRE VIO/YEL WIRE WHT/GRN WIRE

BLU/GRN WIRE BOTTOM CENTER COUPLING POINT IN INTERIOR DRIVER ASSISTANCE SYSTEMS CONTROL MODULE ENGINE SOUND GENERATOR CONTROL MODULE FRONT ROOF MODULE GARAGE DOOR OPENER CONTROL MODULE GRN WIRE GRN/GRY WIRE GRY/GRN WIRE GRY/RED WIRE LEFT FRONT HEADLAMP LEFT FRONT SEAT BELT LEFT REAR SEAT BELT TENSIONER CONTROL MODULE ORG/BRN WIRE ORG/GRY WIRE OVERHEAD CONSOLE PNK WIRE RAIN/LIGHT RECOGNITION SENSOR REAR A/C DISPLAY CONTROL HEAD REAR VIEW CAMERA SYSTEM CONTROL MODULE REDUCING AGENT MEETERING SYSTEM CONTROL MODULE RIGHT FRONT HEADLAMP RIGHT FRONT SEAT BELT RIGHT REAR SEAT BELT TENSIONER CONTROL MODULE TIRE PRESSURE MONITORING CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE W/ ADAPTIVE CRUISE CONTROL W/ DRIVER ASSISTANCE SYSTEM W/ LANE CHANGE ASSISTANCE W/O DRIVER ASSISTANCE SYSTEM W/O LANE CHANGE ASSISTANCE WHT WIRE WHT/GRY WIRE WINDSHIELD WASHER PUMP CONTROL MODULE WIPER MOTOR CONTROL MODULE

AIR BAG CONTROL MODULE ASSEMBLY MOUNT CONTROL MODULE AUXILIARY HEATER CONTROL MODULE BLU/GRN WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN/GRY WIRE DRIVETRAIN CONTROL MODULE GRN WIRE GRY/RED WIRE INTERIOR REAR VIEW MIRROR LANE CHANGE ASSISTANCE CONTROL MODULE LANE CHANGE ASSISTANCE CONTROL MODULE 2 LEVEL CONTROL SYSTEM COMPRESSOR ELECTRONICS NIGHT VISION SYSTEM CONTROL MODULE ORG/BRN WIRE ORG/GRY WIRE PARKING HEATER RADIO RECEIVER PNK WIRE RED/GRY WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE STRUCTURE BORNE SOUND CONTROL MODULE SWAY STABILIZATION CONTROL MODULE SWAY STABILIZATION CONTROL MODULE 2 VIO WIRE VIO/BRN WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE W/ LANE CHANGE ASSISTANCE W/O LANE CHANGE ASSISTANCE YEL/VIO WIRE

BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL DATA BUS ON BOARD DIAGNOSTIC INTERFACE (UNDER LEFT FRONT SEAT) DRIVER VOLUME CONTROL FRONT INFORMATION DISPLAY CONTROL HEAD FRONT INFORMATION DISPLAY CONTROL HEAD 2 GPS ANTENNA SPLITTER GRN WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 MOBILE DEVICE CHARGER 1 NCA WIRE ORG/BRN WIRE RED WIRE ROOF ANTENNA VIO WIRE WHT WIRE YEL/VIO WIRE

BLK WIRE BOTTOM COUPLING POINT IN INTERIOR BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL DATA BUS ON BOARD DIAGNOSTIC INTERFACE DATA BUS ON BOARD DIAGNOSTIC INTERFACE (UNDER LEFT FRONT SEAT) EMERGENCY CALL MODULE SPEAKER EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FRONT ROOF MODULE MICROPHONE UNIT GRN WIRE NCA WIRE ORG/BRN WIRE PNK WIRE WHT WIRE YEL/VIO WIRE
