Audi Q8 I (2018-2023) computer data lines system Wiring diagrams

BLK WIRE BLK/GRY WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/GRY WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT SWITCH DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT ANGLE ADJUSTMENT SWITCH DRIVER SEAT COUPLING POINT DRIVER SEAT DEPTH ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SWITCH DRIVER SEAT SWITCH MODULE GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE

BLU/BRN WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER BACKREST ADJUSTMENT SWITCH DRIVER DOOR CONTROL MODULE DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT ANGLE ADJUSTMENT SWITCH DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SWITCH DRIVER SEAT MEMORY BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE MEMORY SEAT INDICATOR LAMP FUSE 5 FUSE PANEL C GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

ANTI-LOCK BRAKES SYSTEM BATTERY INTERRUPT IGNITER BLK WIRE BOTTOM LEFT COUPLING POINT ON ENGINE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL POWER STEERING MOTOR FUSE 1 GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE ORG/GRY WIRE PNK WIRE POWER STEERING CONTROL MODULE RED WIRE STEERING ANGLE SENSOR STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING TORQUE SENSOR TOP RIGHT COUPLING POINT ON ENGINE YEL WIRE

12-PIN CONNECTOR ABS CONTROL MODULE BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON GRN WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE ORG/GRY WIRE PARKING BRAKE BUTTON PARKING BRAKE INDICATOR LAMP PNK WIRE RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT HEADLAMP RIGHT FRONT TURN SIGNAL BULB RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP FAN RIGHT HEADLAMP TEMPERATURE SENSOR 1 RIGHT HEADLAMP TEMPERATURE SENSOR 2 RIGHT HEADLAMP TEMPERATURE SENSOR 3 RIGHT HEADLAMP TEMPERATURE SENSOR 4 RIGHT HEADLAMP TEMPERATURE SENSOR 5 RIGHT HIGH BEAM HEADLAMP BULB RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT LOW BEAM HEADLAMP BULB WHT/BLK WIRE WHT/GRY WIRE

12-PIN CONNECTOR 4-PIN CONNECTOR ABS CONTROL MODULE BLK WIRE BLK/BRN WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON GRN WIRE GRN/GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE ORG/GRY WIRE PARKING BRAKE BUTTON PARKING BRAKE INDICATOR LAMP PNK WIRE RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT HEADLAMP RIGHT FRONT SIDE MARKER LAMP BULB RIGHT FRONT TURN SIGNAL BULB RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP TEMPERATURE SENSOR 1 RIGHT HEADLAMP TEMPERATURE SENSOR 2 RIGHT HEADLAMP TEMPERATURE SENSOR 3 RIGHT HEADLAMP TEMPERATURE SENSOR 4 RIGHT HIGH BEAM HEADLAMP BULB RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT LOW BEAM HEADLAMP BULB WHT/BLK WIRE WHT/GRY WIRE

ADJUSTMENT MOTOR ADJUSTMENT MOTOR 2 AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR DRIVER SEAT MEMORY BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE MEMORY SEAT INDICATOR LAMP EXTERIOR REAR VIEW MIRROR ADJUSTER FOLDING MOTOR FUSE 5 FUSE PANEL C GRN WIRE GRY WIRE GRY/WHT WIRE GRY/YEL WIRE HEATER HORIZONTAL POSITION SENSOR HOT AT ALL TIMES LANE CHANGE ASSISTANCE WARNING LAMP LEFT FRONT DOOR COUPLING POINT LEFT PERIPHERAL CAMERA MEMORY SEAT POSITIONS 1, 2 BUTTON MIRROR ADJUSTER SWITCH MIRROR SELECTOR SWITCH NAVIGATION SYSTEM NCA WIRE ORG/BRN WIRE PNK WIRE RED WIRE RED/VIO WIRE TURN SIGNAL VERTICAL POSITION SENSOR WHT WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLK/GRY WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/GRY WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER MEMORY SEAT CONTROL MODULE FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT ANGLE ADJUSTMENT BUTTON FRONT PASSENGER SEAT ANGLE ADJUSTMENT MOTOR FRONT PASSENGER SEAT BACKREST ADJUSTMENT SWITCH FRONT PASSENGER SEAT COUPLING POINT FRONT PASSENGER SEAT DEPTH ADJUSTMENT MOTOR FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT SWITCH FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT SWITCH FRONT PASSENGER SEAT SWITCH MODULE GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE

BLU/BRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER MEMORY SEAT CONTROL MODULE FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT ANGLE ADJUSTMENT BUTTON FRONT PASSENGER SEAT ANGLE ADJUSTMENT MOTOR FRONT PASSENGER SEAT BACKREST ADJUSTMENT MOTOR FRONT PASSENGER SEAT BACKREST ADJUSTMENT SWITCH FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT SWITCH FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT SWITCH FRONT PASSENGER SEAT MEMORY BUTTON FRONT PASSENGER SEAT MEMORY SETTINGS CONTROL HEAD FRONT PASSENGER SIDE MEMORY SEAT INDICATOR LAMP FUSE 14 FUSE PANEL E GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COUPLING POINT WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

ACCESS/START AUTHORIZATION BUTTON BLK WIRE BLU/YEL WIRE BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVETRAIN CONTROL MODULE FROM BATTERY INTERRUPT IGNITER (DIAGRAM 1 OF 8) FROM FUSE PANEL H (DIAGRAM 3 OF 8) FUSE 1 FUSE 10 FUSE 11 FUSE 12 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 FUSE PANEL G GENERATOR, VOLTAGE REGULATOR GLOW PLUG FUSE 2 GRN WIRE LEFT FRONT SEAT BELT N/A NOT USED ORG/BRN WIRE RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE RADIATOR FAN SECOND SPEED FUSE REAR A/C DISPLAY CONTROL HEAD REAR LID CONTROL MODULE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR FOOTWELL SECONDARY AIR INJECTION PUMP FUSE STARTER SUPPRESSOR TRANSMISSION CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ MULTI-ZONE CONTROLS WHT/GRY WIRE WHT/VIO WIRE YEL/GRY WIRE

BOTTOM CENTER COUPLING POINT IN INTERIOR BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 3 FUSE 4 GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE ORG/BRN WIRE ORG/GRY WIRE PNK WIRE REAR AXLE STEERING CONTROL MODULE (REAR AXLE ASSEMBLY) REAR AXLE STEERING SENSOR 1, REAR AXLE STEERING SENSOR 2 RED WIRE STEERING RACK POSITION SENSOR WIRE JUNCTION WIRE JUNCTION 2 WIRE JUNCTION 3
