Navigation circuit, w/ amplifier w/o high end sound for Audi Q8 Sportback e-tron I (2022-2024)

BLK/BLU WIRE BLK/YEL WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM FUSE FUSE PANEL H GRN WIRE GRY WIRE GRY/BLK WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT "C" PILLAR) LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT DOOR SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER 2 LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR TREBLE SPEAKER PNK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RELAY & FUSE PANEL 3 RIGHT EFFECTS SPEAKER RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT DOOR SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER +2 RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR TREBLE SPEAKER VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE

BLK WIRE BLK/YEL WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL CENTER SPEAKER CENTER SPEAKER 2 DUAL SUBWOOFER SPEAKER 1 DUAL SUBWOOFER SPEAKER 2 EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FRONT ROOF MODULE MICROPHONE UNIT GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE GRY/VIO WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 (RIGHT SIDE OF DASH) INTERIOR MICROPHONE LEFT EFFECTS SPEAKER LEFT FRONT TREBLE SPEAKER PNK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT TREBLE SPEAKER SUBWOOFER VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE

ANDROID OPERATING SYSTEM CONTROL MODULE ANTENNA BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/RED WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL DVD PLAYER FUSE 10 FUSE 14 FUSE 2 FUSE PANEL F GRN WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 NCA WIRE ORG/ WIRE PNK WIRE RADIO ANTENNA 2 RED/BLK WIRE RED/YEL WIRE W/O TV TUNER

ACCESS/START AUTHORIZATION BUTTON BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE BRN/RED WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL CENTER COUPLING POINT ON LEFT A-PILLAR COMPUTER DATA LINES SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE DRIVER VOLUME CONTROL FUSE 13 FUSE 15 FUSE 7 FUSE PANEL D FUSE PANEL F FUSE PANEL J GRN WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES NCA WIRE ORG/ WIRE ORG/BRN WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RIGHT REAR FOOTWELL ROOF ANTENNA CONTROL MODULE SATELLITE TUNER ANTENNA USB CONNECTION 1 USB DISTRIBUTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE

BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/RED WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM FRONT INFORMATION DISPLAY CONTROL HEAD FRONT INFORMATION DISPLAY CONTROL HEAD 2 FUSE 5 FUSE 8 FUSE 9 FUSE PANEL F GRN WIRE GRN/VIO WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INSTRUMENT CLUSTER CONTROL MODULE MOST DATA BUS CIRCUIT NAVIGATION SYSTEM NAVIGATION SYSTEM (EMERGENCY CALL CIRCUIT) NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRY WIRE PNK WIRE REAR CAMERA CIRCUIT RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE SOUND SYSTEMS VIO WIRE WHT WIRE
