Jet heater circuit for Audi Q7 4M facelift (2019-2024)
Jet heater circuit
BRN WIRE
CENTER WASHER NOZZLE HEATER
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE CARRIER 3
FUSE PANEL B
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT WASHER NOZZLE HEATER
ORG/BRN WIRE
RED WIRE
RED/GRY WIRE
RELAY & FUSE CARRIER 2
RIGHT WASHER NOZZLE HEATER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
YEL WIRE
YEL/WHT WIRE
