A/t circuit for Audi Q7 4M facelift (2019-2024)

ACCUMULATOR SOLENOID AUTOMATIC TRANSMISSION COUPLING POINT AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 5 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 6 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 7 BASIC BLK WIRE BLU/GRY WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM FUSE 4 FUSE 6 FUSE CARRIER 1 FUSE CARRIER 4 FUSE CARRIER 5 FUSE PANEL B FUSE PANEL F GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE ORG/GRY WIRE PARKING LOCK SENSOR PARKING LOCK SOLENOID PNK WIRE RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 SOLENOID VALVE 1 TEMPERATURE SENSOR THERMAL 15 POWER SUPPLY RELAY ENERGIZED TRANSMISSION ASSEMBLY TRANSMISSION CONTROL MODULE TRANSMISSION FLUID COOLING VALVE TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION INPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR WHT WIRE

2.0L TURBO 3.0L TURBO 4-PIN CONNECTOR BLK WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM D/S DIFFERENTIAL LOCK CONTROL MODULE ENGINE/MOTOR CONTROL MODULE FUSE 16 FUSE PANEL C GRN WIRE HOT AT ALL TIMES LEFT MULTI-FUNCTION BUTTONS NCA WIRE ORG/BRN WIRE ORG/VIO WIRE PARKING LOCK IND LAMP PNK WIRE RED WIRE RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL SELECTOR LEVER (BASE OF SHIFTER) SELECTOR LEVER POSITION SENSOR SELECTOR LEVER RELEASE BUTTON, PARKING LOCK BUTTON SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER TRANSMISSION RANGE DISPLAY SHIFT LOCK SOLENOID SIDE OF CARGO AREA) SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL TOUCH RECOGNITION CONTROL MODEL TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON TRANSVERSE SELECTOR LEVER LOCK MOTOR TRANSVERSE SELECTOR LEVER LOCK SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE W/ STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
