Parking assistant circuit, w/ parallel parking & driver assistance for Audi Q7 4M facelift (2019-2024)

BLK WIRE BLK/YEL WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT FRONT BUMPER DRIVER ASSISTANCE SYSTEMS CONTROL MODULE FRONT PARKING AID WARNING BUZZER FUSE 9 FUSE CARRIER 2 FUSE PANEL B GRN WIRE GRN/BLK WIRE GRN/GRY WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT PARALLEL PARKING ASSISTANCE SENSOR LEFT FRONT PARKING AID SENSOR RED/GRN WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARALLEL PARKING ASSISTANCE SENSOR RIGHT FRONT PARKING AID SENSOR VIO WIRE VIO/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

BLK/BRN WIRE BLK/YEL WIRE BLU/VIO WIRE BRN/GRN WIRE CENTER CONSOLE SWITCH MODULE 1 CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM FUSE 11 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARALLEL PARKING ASSISTANCE SENSOR LEFT REAR PARKING AID SENSOR ORG/BRN WIRE PARALLEL PARKING ASSISTANCE BUTTON PARALLEL PARKING ASSISTANCE INDICATOR LAMP PARKING AID BUTTON PARKING AID INDICATOR LAMP RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARALLEL PARKING ASSISTANCE SENSOR RIGHT REAR PARKING AID SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/BLU WIRE WHT/GRN WIRE YEL/GRY WIRE YEL/RED WIRE
