Navigation circuit, w/o amplifier for Audi Q7 4M (2015-2020)

BLK WIRE BLU WIRE BLU/GRY WIRE BLU/RED WIRE BLU/YEL WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER VOLUME CONTROL EXTERNAL AUDIO SOURCE CONNECTION FRONT ROOF MODULE MICROPHONE UNIT FUSE 10 FUSE 5 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT FRONT MICROPHONE MOST DATA BUS CIRCUIT MULTI-MEDIA SYSTEM CONTROL HEAD (CENTER OF DASH) ORG/ WIRE ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT MICROPHONE RIGHT REAR BASS SPEAKER SOUND SYSTEM USB VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

BLK WIRE BLU WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE CENTER INSTRUMENT PANEL COUPLING POINT COMPUTER DATA LINES SYSTEM DISPLAY PIVOT MECHANISM FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 8 FUSE PANEL C GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE MOST DATA BUS CIRCUIT ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT TREBLE SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR TREBLE SPEAKER SOUND SYSTEM SUBWOOFER VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

ANTENNA AMPLIFIER 3 DIGITAL RADIO ANTENNA BLK WIRE BLU WIRE BLU/GRY WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE FUSE 14 FUSE 2 FUSE CARRIER 3 FUSE PANEL C FUSE PANEL F GPS ANTENNA GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT TREBLE SPEAKER LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR TREBLE SPEAKER LTE ANTENNA 1 NCA WIRE ORG/ WIRE RED/BLK WIRE RED/YEL WIRE SATELLITE ANTENNA TELEPHONE ANTENNA VIO WIRE VIO/BRN WIRE VIO/WHT WIRE W/ DIGITAL RADIO WHT/RED WIRE

ANTENNA ANTENNA AMPLIFIER 2 RADIO ANTENNA 2 BLK WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CELLULAR TELEPHONE AMPLIFIER (RIGHT SIDE OF CARGO AREA) CENTER COUPLING POINT IN INTERIOR CENTER SPEAKER GRN WIRE INFORMATION ELECTRONICS CONTROL MODULE 1 LTE ANTENNA 2 NAVIGATION SYSTEM NAVIGATION SYSTEM (REAR VIEW CAMERA CIRCUIT) NCA WIRE ORG/ WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE SOUND SYSTEM (MOST DATA BUS CIRCUIT) TELEPHONE ANTENNA TELEPHONE BASEPLATE (UNDER FRONT CENTER ARMREST) VIO/WHT WIRE WHT WIRE WHT/RED WIRE
