Audi Q7 4M (2015-2020) sunlight photo sensor Wiring diagrams
This page contains all the electrical diagrams for the component. sunlight photo sensor, in which he is found in the car Audi Q7 4M (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sunlight photo sensor (1 of 3)
AIR QUALITY SENSOR
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BLK/BRN WIRE
BLK/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
EVAPORATOR VENT TEMPERATURE SENSOR
FRESH AIR BLOWER FRESH AIR BLOWER CONTROL MODULE
FUSE 1
FUSE 12
FUSE 8
FUSE CARRIER 2
FUSE CARRIER 4
FUSE CARRIER 5
FUSE PANEL B
GRN WIRE
GRY WIRE
HIGH PRESSURE SENSOR
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
HUMIDITY SENSOR IN FRESH AIR INTAKE DUCT
INTERIOR REAR VIEW MIRROR
LEFT FOOTWELL VENT TEMPERATURE SENSOR
LIGHT RECOGNITION SENSOR
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR, HUMIDITY SENSOR
REAR UPPER BODY VENT TEMPERATURE SENSOR
RED WIRE
RED/BLU WIRE
RIGHT FOOTWELL VENT TEMPERATURE SENSOR
SUNLIGHT PHOTO SENSOR
VIO/GRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/o rear controls & second heating system (2 of 3) -> SUNLIGHT PHOTO SENSOR
Wiring diagram sunlight photo sensor (2 of 3)
AIR QUALITY SENSOR
BLK/BRN WIRE
BLK/GRN WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
EVAPORATOR VENT TEMPERATURE SENSOR
FRESH AIR BLOWER FRESH AIR BLOWER CONTROL MODULE
FUSE 8
FUSE CARRIER 2
FUSE PANEL B
GRN WIRE
GRY WIRE
HIGH PRESSURE SENSOR
HOT AT ALL TIMES
HUMIDITY SENSOR IN FRESH AIR INTAKE DUCT
LEFT FOOTWELL VENT TEMPERATURE SENSOR
RED/BLU WIRE
RED/VIO WIRE
RIGHT FOOTWELL VENT TEMPERATURE SENSOR
SEATS SYSTEM
SUNLIGHT PHOTO SENSOR
VIO/WHT WIRE
WHT/BLU WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/ rear controls (2 of 4) -> SUNLIGHT PHOTO SENSOR
Wiring diagram sunlight photo sensor (3 of 3)
AUXILIARY HEATER CONTROL MODULE
AUXILIARY HEATER HEATING ELEMENT
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DEFROSTER DOOR MOTOR
DISPLAY UNIT
EVAPORATOR VENT TEMPERATURE SENSOR
FRONT A/C DISPLAY CONTROL HEAD
FUSE 6
FUSE PANEL C
GRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT PANEL VENT BUTTON
LEFT CENTER VENT MOTOR
LEFT FOOTWELL DOOR MOTOR
LEFT FOOTWELL TEMPERATURE CONTROL DOOR MOTOR
LEFT FOOTWELL VENT TEMPERATURE SENSOR
LEFT FRONT UPPER BODY VENT TEMPERATURE SENSOR
LEFT SIDE VENT MOTOR
LEFT TEMPERATURE CONTROL DOOR MOTOR
ORG/BLU WIRE
ORG/BRN WIRE
ORG/WHT WIRE
ORG/YEL WIRE
REAR TEMPERATURE CONTROL DOOR MOTOR
RED WIRE
RED/BRN WIRE
RED/YEL WIRE
RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR
SUNLIGHT PHOTO SENSOR
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
WIRE JUNCTION
WIRE JUNCTION FUSE 1
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/ second heating system (1 of 6) -> SUNLIGHT PHOTO SENSOR
