Audi Q7 4M (2015-2020) power pivoting trailer hitch button Wiring diagram
This page shows the only wiring diagram for the component.power pivoting trailer hitch button, which is found in the car Audi Q7 4M (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power pivoting trailer hitch button (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVETRAIN CONTROL MODULE (FRONT OF CENTER FLOOR CONSOLE)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/WHT WIRE
LEVEL CONTROL PUMP TEMPERATURE SENSOR
LOAD LEVEL BUTTON
ORG/BRN WIRE
PNK WIRE
POWER PIVOTING TRAILER HITCH BUTTON
RED/GRY WIRE
RED/WHT WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
TOWING RECOGNITION CONTROL MODULE
VIO/YEL WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Electronic suspension circuit (2 of 3) -> POWER PIVOTING TRAILER HITCH BUTTON
