Audi Q7 4M (2015-2020) microphone unit Wiring diagram
This page shows the only wiring diagram for the component.microphone unit, which is found in the car Audi Q7 4M (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram microphone unit (1 of 1)
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/BLU WIRE
CENTER COUPLING POINT IN INTERIOR
COUPLING POINT IN THE LEFT FRONT DOOR
COUPLING POINT IN THE RIGHT FRONT DOOR
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
EMERGENCY CALL MODULE ANTENNA
EMERGENCY CALL MODULE SPEAKER
GRN WIRE
GRN/WHT WIRE
GRY/YEL WIRE
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT DOOR CONTOUR ILLUMINATION LAMP
LEFT FRONT DOOR COUPLING POINT
MICROPHONE UNIT
NCA WIRE
PNK WIRE
RED/BLU WIRE
RIGHT FRONT DOOR CONTOUR ILLUMINATION LAMP
RIGHT FRONT DOOR COUPLING POINT
STEERING COLUMN ELECTRONICS CONTROL MODULE
VIO/GRN WIRE
VIO/YEL WIRE
W/ EMERGENCY CALL MODULE
W/ HEAT INSULATING WINDSHIELD
W/O HEAT INSULATING WINDSHIELD
WHT WIRE
YEL/VIO WIRE
Go to component -> Computer data lines circuit (6 of 6) -> MICROPHONE UNIT
