Audi Q7 4M (2015-2020) bose except bose w/ heat insulating windshield w/o heat insulating windshield Wiring diagram
This page shows the only wiring diagram for the component.bose except bose w/ heat insulating windshield w/o heat insulating windshield, which is found in the car Audi Q7 4M (2015-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bose except bose w/ heat insulating windshield w/o heat insulating windshield (1 of 1)
BLK WIRE
BLU WIRE
BOSE EXCEPT BOSE W/ HEAT INSULATING WINDSHIELD W/O HEAT INSULATING WINDSHIELD
BRN WIRE
BRN/BLU WIRE
CENTER COUPLING POINT IN INTERIOR
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE ANTENNA
EMERGENCY CALL MODULE MICROPHONE
EMERGENCY CALL MODULE SPEAKER
FRONT ROOF MODULE
FUSE 14
FUSE 8
FUSE CARRIER 5
FUSE PANEL B
FUSE PANEL C
GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT MICROPHONE
MICROPHONE UNIT (FRONT ROOF CONSOLE)
NCA WIRE
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
VIO/RED WIRE
WHT WIRE
Go to component -> Emergency call circuit -> BOSE EXCEPT BOSE W/ HEAT INSULATING WINDSHIELD W/O HEAT INSULATING WINDSHIELD
