Audi Q7 4L facelift (2009-2015) w/ light switch w/o light switch Wiring diagram
This page shows the only wiring diagram for the component.w/ light switch w/o light switch, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ light switch w/o light switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE 2 (RIGHT SIDE OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DRIVER DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS)
DRIVER'S DOOR CENTRAL LOCKING LOCK UNIT
DRIVER'S DOOR CONTROL MODULE (DRIVER'S DOOR)
DRIVER'S DOOR WARNING LIGHT (W/ AUXILIARY LAMPS)
DRIVER'S MAP/READING LIGHT
FRONT PASSENGER DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS)
FRONT PASSENGER'S DOOR CENTRAL LOCKING LOCK UNIT
FRONT PASSENGER'S DOOR CONTROL MODULE (FRONT PASSENGER'S DOOR)
FRONT PASSENGER'S DOOR WARNING LIGHT (W/ AUXILIARY LAMPS)
FRONT PASSENGER'S MAP/READING LIGHT
FRONT ROOF CONTROL MODULE
GRY WIRE
GRY/BLU WIRE
GRY/VIO WIRE
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT ILLUMINATION CIRCUIT
LAMPS)
LEFT FRONT ENTRY LIGHT (W/ AUXILIARY
LEFT INTERIOR LIGHT
MIRRORS SYSTEM
ORG/BRN WIRE
ORG/GRN WIRE
REAR COURTESY LIGHT
REAR INTERIOR LIGHTS ASSEMBLY
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT ENTRY LIGHT
RIGHT INTERIOR LIGHT
VIO WIRE
W/ AUXILIARY LAMPS
W/ LIGHT SWITCH W/O LIGHT SWITCH
WHT WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> W/ LIGHT SWITCH W/O LIGHT SWITCH
