Audi Q7 4L facelift (2009-2015) w/ electronic rear lid opener w/o electronic rear lid opener Wiring diagram

This page shows the only wiring diagram for the component.w/ electronic rear lid opener w/o electronic rear lid opener, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram w/ electronic rear lid opener w/o electronic rear lid opener (1 of 1)

Wiring diagram w/ electronic rear lid opener w/o electronic rear lid opener for Audi Q7 4L facelift (2009-2015)

Get access

BLK WIRE BLK/BRN WIRE BLU WIRE BRN WIRE CENTRAL LOCKING SAFE INDICATOR LAMP CONTROL MODULE MOTOR) DRIVER'S INTERIOR LOCK SWITCH FRONT PASSENGER INTERIOR LOCK SWITCH GRN WIRE GRN/GRY WIRE GRY/GRN WIRE GRY/YEL WIRE LEFT REAR INTERIOR LOCK SWITCH LICENSE PLATE LIGHT, REAR LID LOCK CYLINDER UNLOCK BUTTON REAR LID ALARM SWITCH, REAR LID CENTRAL LOCKING SYSTEM BUTTON REAR LID CONTROL MODULE 2 (IN REAR LID REAR LID REMOTE RELEASE BUTTON, FUEL FILLER DOOR RELEASE BUTTON RED WIRE RED/GRN WIRE RED/YEL WIRE TRUNK LID ALARM SWITCH, REAR LID CENTRAL LOCKING SYSTEM MOTOR VIO WIRE VIO/BLU WIRE VIO/RED WIRE W/ ELECTRONIC REAR LID OPENER W/O ELECTRONIC REAR LID OPENER WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> Power door locks circuit (2 of 3) -> W/ ELECTRONIC REAR LID OPENER W/O ELECTRONIC REAR LID OPENER
