Audi Q7 4L facelift (2009-2015) sunroof blind motor Wiring diagram

12 PIN CONNECTOR (NOT USED) BRN WIRE BRN/BLK WIRE BRN/GRY WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE 2 (RIGHT SIDE OF LUGGAGE COMPT) FOLDING SUNROOF BUTTON 1 FOLDING SUNROOF BUTTON 2 FUSE 8 FUSE 9 FUSE CARRIER FUSE 7 FUSE PANEL C (RIGHT REAR ENGINE COMPT) GRY/BLU WIRE HOT AT ALL TIMES ORG/ WIRE POWER SUNROOF CONTROL MODULE (INTEGRAL W/ SUNROOF MOTOR) REAR SLIDING SUNROOF CONTROL MODULE (REAR SUNROOF) REAR SUNROOF MOTOR REAR SUNROOF SWITCH RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE ROOF BLIND CONTROL MODULE (ON REAR OF PANORAMA SUNROOF) SUNROOF BLIND MOTOR SUNROOF MOTOR SUNROOF REGULATOR SUNROOF SWITCH TILT SUNROOF BUTTON 1 TILT SUNROOF BUTTON 2 VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/YEL WIRE
