Audi Q7 4L facelift (2009-2015) sunroof adjustment Wiring diagram
This page shows the only wiring diagram for the component.sunroof adjustment, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunroof adjustment (1 of 1)
ASHTRAY, CUP SOCKET 2 HOLDER (W/ RIGHT ILLUMI- FRONT NATION CENTER CONSOLE)
ASR/ESP BUTTON
BLK WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
CIGARETTE LIGHTER
COMPUTER DATA LINES SYSTEM
DISPLAY, GLOVE COMPART- MENT BUTTON
EMERGENCY FLASHER BUTTON CENTER INSTRU- MENT PANEL VENT ILLUMI- NATION
FRONT ROOF CONTROL MODULE
FRONT/ CENTER CONSOLE CONTROL HEAD
FUSE CARRIER FUSE
FUSE PANEL SB (LEFT INSTRUMENT PANEL)
GARAGE DOOR OPENER CONTROL HEAD
GRY WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HEADLIGHT SWITCH ILLUMINATION
HITCH SWITCH
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LANE CHANGE ASSIST- ANCE BUTTON
LEFT INSTRU- MENT PANEL VENT ILLUMI- NATION
LEFT REAR HEATED SEAT REGU- LATING SWITCH
LIGHT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
POWER PIVOTING TRAILER
REAR CENTER AIR VENT ILLUMI- NATION
REAR COURTESY LIGHT
REAR SUNROOF SWITCH
REGULATOR (IF EQUIPPED)
RIGHT INSTRU- MENT PANEL VENT ILLUMI- NATION
RIGHT REAR HEATED SEAT REGU- LATING SWITCH
SOCKET
SOCKET 4 (W/ RIGHT REAR CENTER CONSOLE)
SUNROOF ADJUSTMENT
SUNROOF SWITCH
TELEPHONE BASE PLATE
TOWING RECOGNITION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE 1 (BEHIND LEFT SIDE OF DASH)
VIO WIRE
W/ BLUETOOTH
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Instrument illumination circuit (1 of 2) -> SUNROOF ADJUSTMENT
