Audi Q7 4L facelift (2009-2015) steering wheel control module Wiring diagrams
This page contains all the electrical diagrams for the component. steering wheel control module, in which he is found in the car Audi Q7 4L facelift (2009-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
steering wheel control module wiring diagram (1 of 3)
BLK WIRE
BLK/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE PANEL B
GRY WIRE
HEATED STEERING WHEEL (IF EQUIPPED)
HEATED STEERING WHEEL SENSOR
HOT AT ALL TIMES FUSE CARRIER FUSE 11
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED FUSE CARRIER FUSE 6
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/GRY WIRE
SPIRAL SPRING
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (IN STEERING COLUMN ASSEMBLY)
STEERING WHEEL CONTROL MODULE
STEERING WHEEL HEATING BUTTON (IF EQUIPPED)
VIO WIRE
Go to component -> Heated steering wheel circuit -> STEERING WHEEL CONTROL MODULE
steering wheel control module wiring diagram (2 of 3)
BLK/BRN WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIRECTIONAL STABILIZATION ASSISTANCE BUTTON
DIRECTIONAL STABILIZATION ASSISTANCE CONTROL MODULE (TOP CENTER OF WINDSHIELD)
DIRECTIONAL STABILIZATION ASSISTANCE IND
DIRECTIONAL STABILIZATION ASSISTANCE WINDSHIELD HEATER
DISPLAY UNIT
FUSE CARRIER 3 FUSE 4
FUSE PANEL B (LEFT INSTRUMENT PANEL)
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
LEFT MULTI-FUNCTION BUTTONS
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
SPIRAL SPRING
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (IN STEERING COLUMN ASSEMBLY)
STEERING WHEEL CONTROL MODULE
STEERING WHEEL VIBRATION MOTOR
Go to component -> Lane departure warning circuit -> STEERING WHEEL CONTROL MODULE
steering wheel control module wiring diagram (3 of 3)
AUXILIARY HYDRAULIC PUMP CONTROL MODULE (W/ STOP/START SYSTEM)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING OIL VALVE
FUSE 11 FUSE CARRIER 1
FUSE 6 FUSE CARRIER 3
FUSE PANEL B (LEFT INSTRUMENT PANEL)
FUSE PANEL C (RIGHT REAR ENGINE COMPT)
GRY WIRE
HOT AT ALL TIMES
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/GRY WIRE
SPIRAL SPRING
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (IN STEERING COLUMN ASSEMBLY)
STEERING WHEEL CONTROL MODULE
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 2
TRANSMISSION HYDRAULIC PUMP RELAY
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
Go to component -> Transmission circuit (3 of 3) -> STEERING WHEEL CONTROL MODULE
