Audi Q7 4L facelift (2009-2015) power supply relay (terminal Wiring diagrams
This page contains all the electrical diagrams for the component. power supply relay (terminal, in which he is found in the car Audi Q7 4L facelift (2009-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
power supply relay (terminal wiring diagram (1 of 2)
ACCESS/START CONTROL MODULE
BLK WIRE
BLU WIRE
BRN WIRE
DIGITAL SOUND SYSTEM CONTROL MODULE
DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER'S POWER SEAT SWITCH ASSEMBLY (W/O MEMORY)
FROM FUSE PANEL D (DIAGRAM 1 OF 7)
FRONT PASSENGER'S POWER SEAT SWITCH ASSEMBLY (W/O MEMORY)
FRONT PASSENGER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH (W/O MEMORY)
FUSE
FUSE 11
FUSE 30
FUSE 51
FUSE 6 FUSE 5
FUSE 7
FUSE 8
FUSE CARRIER 2
FUSE PANEL F (RIGHT SIDE LUGGAGE COMPT)
GRN WIRE
LEFT WASHER NOZZLE HEATER
NAVIGATION SYSTEM CONTROL MODULE (W/ CD DRIVE)
NCA WIRE
PASSENGER'S MEMORY SEAT CONTROL MODULE (W/ MEMORY)
POWER SUPPLY RELAY (TERMINAL
RADIO ANTENNA AMPLIFIER
REAR WINDOW WIPER MOTOR
RED WIRE
RED/BLU WIRE
RELAY & FUSE CARRIER (CENTER INSTRUMENT PANEL)
RIGHT WASHER NOZZLE HEATER
SATELLITE RADIO (IF EQUIPPED)
VIO WIRE
W/ DRIVER'S POWER SEAT
YEL WIRE
Go to component -> 3.0l sc, power distribution circuit (7 of 7) -> POWER SUPPLY RELAY (TERMINAL
power supply relay (terminal wiring diagram (2 of 2)
ACCESS/START CONTROL MODULE
ANTENNA AMPLIFIER
BLK WIRE
BLU WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
DIGITAL SOUND DIGITAL TV TUNER SYSTEM CONTROL MODULE
DIGITAL SOUND SYSTEM CONTROL MODULE
DIGITAL SOUND TOWING RECOGNITION CONTROL MODULE SYSTEM CONTROL MODULE 2
DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER'S POWER SEAT SWITCH ASSEMBLY (W/O MEMORY)
DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
FROM FUSE PANEL D (DIAGRAM 1 OF 7)
FRONT PASSENGER'S POWER SEAT SWITCH ASSEMBLY (W/O MEMORY)
FRONT PASSENGER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH (W/O MEMORY)
FUSE
FUSE 1
FUSE 3 FUSE 2
FUSE 30
FUSE 4 FUSE FUSE
FUSE 51
FUSE 6
FUSE 7
FUSE 8
FUSE 9 FUSE 11
FUSE FUSE
FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT) FUSE CARRIER 3
FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT) FUSE FUSE 5 CARRIER
GRN WIRE
GRY WIRE
LEFT WASHER NOZZLE HEATER
LEVEL CONTROL SYSTEM CONTROL MODULE
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE
NAVIGATION SYSTEM CONTROL MODULE (W/ CD DRIVE)
NCA WIRE
PASSENGER'S MEMORY SEAT CONTROL MODULE (W/ MEMORY)
POWER SUPPLY RELAY (TERMINAL
RADIO
REAR LID CONTROL MODULE
REAR LID CONTROL MODULE 2
REAR WINDOW WIPER MOTOR
RED WIRE
RED/BLU WIRE
RELAY & FUSE CARRIER (CENTER INSTRUMENT PANEL)
RIGHT WASHER NOZZLE HEATER
SATELLITE RADIO (IF EQUIPPED)
VIO WIRE
W/ BANG, OLUFSEN
W/ DRIVER'S POWER SEAT
WHT WIRE
YEL WIRE
Go to component -> 3.0l turbo diesel, power distribution circuit (7 of 7) -> POWER SUPPLY RELAY (TERMINAL
