Audi Q7 4L facelift (2009-2015) left rear exterior door handle touch sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear exterior door handle touch sensor, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear exterior door handle touch sensor (1 of 1)
2 2 4 4 1 1 3.0L SC 3.0L (TURBO DIESEL)
ABS CONTROL MODULE
AUXILIARY VIDEO/ AUDIO CONNECTION MODULE
BRN WIRE
COOLANT PUMP
DRIVER BACKREST HEATING ELEMENT
DRIVER SEAT BOLSTER HEATER
DRIVER'S POWER SEAT SWITCH ASSEMBLY
DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
ENGINE CONTROL MODULE (ECM)
HIGH PRESSURE SENSOR
LEFT FRONT HEATED SEAT
LEFT FRONT SEAT VENTILATION CONTROL MODULE
LEFT REAR DOOR CONTROL MODULE
LEFT REAR DOOR HANDLE SWITCH
LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE
NCA WIRE
RELAY & FUSE PANEL E-BOX (LEFT SIDE OF PLENUM CHAMBER)
Go to component: -> Ground distribution circuit (4 of 7) -> LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
