Audi Q7 4L facelift (2009-2015) left rear ashtray illumination Wiring diagram

ALARM SYSTEM OFF SWITCH BLK WIRE BLU WIRE BLU/BRN WIRE BRN WIRE BRN/GRN WIRE CENTRAL LOCKING SAFE INDICATOR LAMP COMPUTER DATA LINES SYSTEM DRIVER DOOR OPENER ILLUMI- NATION DRIVER'S DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS) DRIVER'S DOOR CONTROL MODULE (DRIVER'S DOOR) DRIVER'S DOOR WARNING LIGHT (W/ AUXILIARY LAMPS) DRIVER'S INTERIOR LOCK SWITCH DRIVER'S SEAT MEMORY PROGRAM SWITCH (IF EQUIPPED) FRONT PASSENGER FRONT PASSENGER DOOR OPENER ILLUMINATION FRONT PASSENGER'S DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS) FRONT PASSENGER'S DOOR CONTROL MODULE (FRONT PASSENGER'S DOOR) FRONT PASSENGER'S DOOR WARNING LIGHT (W/ AUXILIARY LAMPS) GRN WIRE INTERIOR LOCK SWITCH LEFT FRONT ENTRY LIGHT LEFT REAR ASHTRAY ILLUMINATION LEFT REAR DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS) LEFT REAR DOOR CONTROL MODULE (LEFT REAR DOOR) LEFT REAR DOOR OPENER ILLUMI- NATION LEFT REAR DOOR WARNING LIGHT LEFT REAR INTERIOR LOCK SWITCH LEFT REAR POWER WINDOW SWITCH MIRROR ADJUST- MENT SWITCH ORG/BRN WIRE ORG/GRN WIRE PASSENGER DOOR WINDOW REGULATOR SWITCH POWER WINDOW CONTROL HEAD REAR LID REMOTE CONTROL LOCK SWITCH RIGHT FRONT ENTRY LIGHT RIGHT REAR ASHTRAY ILLUMINATION RIGHT REAR DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS) RIGHT REAR DOOR CONTROL MODULE (RIGHT REAR DOOR) RIGHT REAR DOOR OPENER ILLUMINATION RIGHT REAR DOOR WARNING LIGHT (W/ AUXILIARY LAMPS) RIGHT REAR ENTRY LIGHT (W/ AUXILIARY LAMPS) RIGHT REAR INTERIOR LOCK SWITCH RIGHT REAR POWER WINDOW SWITCH W/ AUXILIARY LAMPS
