Audi Q7 4L facelift (2009-2015) instrument panel temperature sensor Wiring diagram

A/C COMPRESSOR REGULATOR VALVE BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE CLIMATRONIC CONTROL MODULE (IN UPPER CENTER CONSOLE) COMPUTER DATA LINES SYSTEM FRESH AIR BLOWER FRESH AIR BLOWER CONTROL MODULE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HUMIDITY SENSOR INSTRUMENT PANEL TEMPERATURE SENSOR INTERIOR TEMPERATURE SENSOR FAN LEFT CENTER VENT MOTOR, POSITION SENSOR (HVAC UNIT) LEFT FOOTWELL DOOR MOTOR, POSITION SENSOR LEFT TEMPERATURE DOOR MOTOR, POTENTIOMETER/ ACTUATOR ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/YEL WIRE PNK/GRN WIRE PNK/WHT WIRE RECIRCULATION DOOR MOTOR, POSITION SENSOR RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOOTWELL DOOR MOTOR, POSITION SENSOR SEATS SYSTEM VIO WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE W/ SEAT VENTILATION WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE
