Audi Q7 4L facelift (2009-2015) heating element temper- ature sensor Wiring diagram
This page shows the only wiring diagram for the component.heating element temper- ature sensor, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heating element temper- ature sensor (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
FUSE CARRIER 1 FUSE 1
FUSE CARRIER FUSE 11
FUSE PANEL C
GRN WIRE
GRY/BLU WIRE
HEATING ELEMENT
HEATING ELEMENT TEMPER- ATURE SENSOR
HOT AT ALL TIMES
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR HEATED SEAT
LEFT REAR HEATED SEAT REGULATING SWITCH
OCCUPIED SENSOR
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR HEATED SEAT
RIGHT REAR HEATED SEAT REGULATING SWITCH
TEMPER- ATURE SENSOR
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Rear heated seats circuit, without rear climatronic -> HEATING ELEMENT TEMPER- ATURE SENSOR
