Audi Q7 4L facelift (2009-2015) glove compart- ment light Wiring diagram

BLK WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE 1 (RIGHT SIDE OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM DRIVER'S VANITY MIRROR FRONT PASS- ENGER'S VANITY MIRROR FUSE CARRIER FUSE FUSE PANEL SB (LEFT INSTRUMENT PANEL) GLOVE COMPART- MENT LAMP SWITCH REAR LID LOCK BUTTON IN LUGGAGE COMPARTMENT GLOVE COMPART- MENT LIGHT GRN WIRE GRY/VIO WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT LAMP CONTACT SWITCH LEFT FOOTWELL LIGHT LEFT LUGGAGE COMPARTMENT LIGHT LEFT REAR CENTRAL LOCKING LOCK UNIT (W/ CHILD LEFT REAR DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS) LEFT REAR DOOR CONTROL MODULE (LEFT REAR DOOR) LEFT REAR DOOR WARNING LIGHT (W/ AUXILIARY LAMPS) LEFT REAR ENTRY LIGHT (W/ AUXILIARY LAMPS) LEFT REAR FOOTWELL LIGHT NCA WIRE ORG/BRN WIRE ORG/GRN WIRE REAR LID COURTESY LAMP RED WIRE RED/BLK WIRE RED/GRN WIRE RED/VIO WIRE RIGHT FOOTWELL LIGHT RIGHT LUGGAGE COMPARTMENT LIGHT RIGHT REAR CENTRAL LOCKING LOCK UNIT (W/ CHILD SAFETY LOCK) RIGHT REAR DOOR AMBIENT LIGHTING BULB (W/ AUXILIARY LAMPS) RIGHT REAR DOOR CONTROL MODULE (RIGHT REAR DOOR) RIGHT REAR DOOR WARNING LIGHT (W/ AUXILIARY LAMPS) RIGHT REAR ENTRY LIGHT (W/ AUXILIARY LAMPS) RIGHT REAR FOOTWELL LIGHT SAFETY LOCK) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE 1 (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/YEL WIRE YEL WIRE YEL/BRN WIRE
