Audi Q7 4L facelift (2009-2015) fuel metering valve Wiring diagrams
This page contains all the electrical diagrams for the component. fuel metering valve, in which he is found in the car Audi Q7 4L facelift (2009-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuel metering valve (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CAMSHAFT ADJUSTMENT VALVE 1
CHARGE AIR COOLING PUMP
COOLANT FAN CONTROL MODULE
COOLANT FAN CONTROL MODULE 2
CRANKCASE VENTILATION SHUT-OFF VALVE
ENGINE COMPONENT POWER SUPPLY RELAY
ENGINE CONTROL MODULE (ECM)
FROM BATTERY JUMP START TERMINAL (DIAGRAM 1 OF 7)
FROM RELAY & FUSE PANEL E-BOX (DIAGRAM 1 OF 7)
FROM RELAY & FUSE PANEL E-BOX (DIAGRAM 4 OF 7)
FUEL METERING VALVE
FUSE 10
FUSE 13
FUSE 14
FUSE 15
FUSE 9 FUSE 8
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR 1
HEATED OXYGEN SENSOR 2
HEATER
HEATER 2
HIGH PRESSURE SENSOR
INTAKE MANIFOLD RUNNER CONTROL (IMRC) VALVE
LEAK DETECTION PUMP (LDP)
NCA WIRE
OIL PRESSURE REGULATION VALVE
OXYGEN SENSOR
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RELAY & FUSE PANEL E-BOX (LEFT SIDE OF PLENUM CHAMBER)
SECONDARY AIR INJECTION (AIR) SOLENOID VALVE
TO RELAY & FUSE PANEL E-BOX (DIAGRAM 4 OF 7)
WHT WIRE
YEL WIRE
Go to component -> 3.0l sc, power distribution circuit (4 of 7) -> FUEL METERING VALVE
Wiring diagram fuel metering valve (2 of 2)
AUTOMATIC GLOW TIME CONTROL MODULE
BLK WIRE
BLU WIRE
BRN WIRE
COOLANT CIRCULATION PUMP RELAY
COOLANT FAN CONTROL (FC) CONTROL MODULE
COOLANT FAN CONTROL MODULE
COOLANT FAN CONTROL MODULE 2
CYLINDER HEAD COOLANT VALVE
ELECTRO HYDRAULIC ENGINE MOUNT SOLENOID VALVE
ENGINE CONTROL MODULE (ECM)
EXHAUST GAS RECIRCULATION (EGR) COOLER SWITCH-OVER VALVE
FROM BATTERY JUMP START TERMINAL (DIAGRAM 1 OF 7)
FROM RELAY & FUSE PANEL E-BOX (DIAGRAM 1 OF 7)
FUEL METERING VALVE
FUEL PRESSURE REGULATOR VALVE
FUSE 1
FUSE 10
FUSE 11
FUSE 12 FUSE 16
FUSE 13
FUSE 14 FUSE 18
FUSE 17
FUSE 2
FUSE 3
FUSE 4
FUSE 6 FUSE 5
FUSE 7
FUSE 9
GRN WIRE
GRY WIRE
HEAT SETTING RELAY 3
HEATER
HIGH HEAT HEAT HEAT SETTING OUTPUT OUTPUT RELAY 3 RELAY RELAY
HIGH HEAT OUTPUT RELAY
HIGH PRESSURE SENSOR
LOW HEAT OUTPUT RELAY
MAP CONTROLLED ENGINE COOLING THERMOSTAT
MASS AIR REDUCING FLOW (MAF) AGENT SENSOR PUMP
NCA WIRE
OIL PRESSURE REGULATION VALVE
OXYGEN SENSOR
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY & FUSE CARRIER (CENTER INSTRUMENT PANEL)
RELAY & FUSE PANEL E-BOX (LEFT SIDE OF PLENUM CHAMBER)
RELAY & FUSE PANEL E-BOX (LEFT SIDE OF PLENUM CHAMBER) FUSE 8
RELAY & FUSE PANEL FUSE 15 E-BOX (LEFT SIDE OF PLENUM CHAMBER)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> 3.0l turbo diesel, power distribution circuit (6 of 7) -> FUEL METERING VALVE
