Audi Q7 4L facelift (2009-2015) front passenger's safety belt tensioner igniter 1 Wiring diagram

This page shows the only wiring diagram for the component.front passenger's safety belt tensioner igniter 1, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger's safety belt tensioner igniter 1 (1 of 1)

Wiring diagram front passenger's safety belt tensioner igniter 1 for Audi Q7 4L facelift (2009-2015)

Get access

BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/YEL WIRE DRIVER'S SAFETY BELT TENSIONER IGNITER 1 FRONT PASSENGER AIR BAG OFF-KEY SWITCH FRONT PASSENGER SEAT OCCUPIED SENSOR (IF EQUIPPED) (UNDER FRONT PASSENGER SEAT) FRONT PASSENGER'S HEAD CURTAIN AIR BAG IGNITER FRONT PASSENGER'S SAFETY BELT TENSIONER IGNITER 1 FRONT PASSENGER'S SIDE AIR BAG IGNITER (RIGHT SIDE FRONT PASSENGER SEAT) GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE NCA WIRE REAR SAFETY BELT (DRIVER'S SIDE) TENSIONER IGNITER REAR SAFETY BELT (FRONT PASSENGER'S SIDE) TENSIONER IGNITER RED WIRE SOLID STATE VIO WIRE VIO/BRN WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

Go to component: -> Supplemental restraints circuit (2 of 3) -> FRONT PASSENGER'S SAFETY BELT TENSIONER IGNITER 1
