Audi Q7 4L facelift (2009-2015) driver's seat memory program switch (if equipped) wiring diagram
This page shows the only wiring diagram for the component.driver's seat memory program switch (if equipped), which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
driver's seat memory program switch (if equipped) wiring diagram (1 of 1)
ALARM SYSTEM OFF SWITCH
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
CENTRAL LOCKING SAFE INDICATOR LAMP
COMPUTER DATA LINES SYSTEM
DRIVER DOOR OPENER ILLUMI- NATION
DRIVER'S DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS)
DRIVER'S DOOR CONTROL MODULE (DRIVER'S DOOR)
DRIVER'S DOOR WARNING LIGHT (W/ AUXILIARY LAMPS)
DRIVER'S INTERIOR LOCK SWITCH
DRIVER'S SEAT MEMORY PROGRAM SWITCH (IF EQUIPPED)
FRONT PASSENGER
FRONT PASSENGER DOOR OPENER ILLUMINATION
FRONT PASSENGER'S DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS)
FRONT PASSENGER'S DOOR CONTROL MODULE (FRONT PASSENGER'S DOOR)
FRONT PASSENGER'S DOOR WARNING LIGHT (W/ AUXILIARY LAMPS)
GRN WIRE
INTERIOR LOCK SWITCH
LEFT FRONT ENTRY LIGHT
LEFT REAR ASHTRAY ILLUMINATION
LEFT REAR DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS)
LEFT REAR DOOR CONTROL MODULE (LEFT REAR DOOR)
LEFT REAR DOOR OPENER ILLUMI- NATION
LEFT REAR DOOR WARNING LIGHT
LEFT REAR INTERIOR LOCK SWITCH
LEFT REAR POWER WINDOW SWITCH
MIRROR ADJUST- MENT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER DOOR WINDOW REGULATOR SWITCH
POWER WINDOW CONTROL HEAD
REAR LID REMOTE CONTROL LOCK SWITCH
RIGHT FRONT ENTRY LIGHT
RIGHT REAR ASHTRAY ILLUMINATION
RIGHT REAR DOOR AMBIENT LIGHTING (W/ AUXILIARY LAMPS)
RIGHT REAR DOOR CONTROL MODULE (RIGHT REAR DOOR)
RIGHT REAR DOOR OPENER ILLUMINATION
RIGHT REAR DOOR WARNING LIGHT (W/ AUXILIARY LAMPS)
RIGHT REAR ENTRY LIGHT (W/ AUXILIARY LAMPS)
RIGHT REAR INTERIOR LOCK SWITCH
RIGHT REAR POWER WINDOW SWITCH
W/ AUXILIARY LAMPS
Go to component -> Instrument illumination circuit (2 of 2) -> DRIVER'S SEAT MEMORY PROGRAM SWITCH (IF EQUIPPED)
