Audi Q7 4L facelift (2009-2015) driver's seat height adjustment motor Wiring diagrams

This page contains all the electrical diagrams for the component. driver's seat height adjustment motor, in which he is found in the car Audi Q7 4L facelift (2009-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver's seat height adjustment motor (1 of 2)

Wiring diagram driver's seat height adjustment motor for Audi Q7 4L facelift (2009-2015)

Get access

BLK/BLU WIRE BLK/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR (W/ CLIMATE SEAT) (DRIVER SEAT BACKREST) DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER'S SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR DRIVER'S SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR GRN/BLK WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE (BOTTOM OF DRIVER SEAT) ORG/BRN WIRE ORG/GRN WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER/ INSTRUMENT PANEL CENTER (CENTER INSTRUMENT PANEL) VIO WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/VIO WIRE

Go to component: -> Driver"s memory seat circuit (1 of 2) -> DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR
