Audi Q7 4L facelift (2009-2015) door assembly) Wiring diagram
This page shows the only wiring diagram for the component.door assembly), which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door assembly) (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR ASSEMBLY)
DRIVER'S DOOR CONTROL MODULE (DRIVER'S DOOR)
DRIVER'S DOOR POWER WINDOW CONTROL HEAD
DRIVER'S WINDOW REGULATOR MOTOR (IN DRIVER
FUSE
FUSE CARRIER 1
FUSE PANEL B (LEFT INSTRUMENT PANEL)
HOT AT ALL TIMES
LEFT FRONT WINDOW REGULATOR SWITCH
LEFT REAR DOOR CONTROL MODULE (LEFT REAR DOOR)
LEFT REAR POWER WINDOW SWITCH
LEFT REAR WINDOW REGULATOR SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT WINDOW REGULATOR SWITCH
RIGHT REAR WINDOW REGULATOR SWITCH
VIO/GRY WIRE
WHT/YEL WIRE
YEL/BLK WIRE
Go to component -> Power windows circuit (1 of 2) -> DOOR ASSEMBLY)
