Audi Q7 4L facelift (2009-2015) control valve control module Wiring diagram

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CONTROL VALVE CONTROL MODULE ENGINE COOLANT LEVEL (ECL) WARNING SWITCH FUEL LEVEL SENSOR 2 (LEFT SIDE FUEL TANK) FUEL LEVEL SENSOR, TRANSFER FUEL PUMP (RIGHT SIDE FUEL TANK) FUEL PUMP (FP) CONTROL MODULE (FUEL TANK) GRN WIRE GRN/BLU WIRE GRY WIRE INTAKE AIR TEMPERATURE (IAT) SENSOR 2, CHARGE AIR PRESSURE SENSOR 2 RED/BLK BRN WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SECONDARY AIR INJECTION (AIR) PUMP MOTOR SECONDARY AIR INJECTION (AIR) PUMP RELAY VIO/GRN WIRE VIO/WHT WIRE VIO/YEL WIRE W/ TANK PREWIRING WHT WIRE WHT/GRY WIRE YEL WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE
