Audi Q7 4L facelift (2009-2015) control module motor) wiring diagram

BLK WIRE BLK/BRN WIRE BLU WIRE BRN WIRE CENTRAL LOCKING SAFE INDICATOR LAMP CONTROL MODULE MOTOR) DRIVER'S INTERIOR LOCK SWITCH FRONT PASSENGER INTERIOR LOCK SWITCH GRN WIRE GRN/GRY WIRE GRY/GRN WIRE GRY/YEL WIRE LEFT REAR INTERIOR LOCK SWITCH LICENSE PLATE LIGHT, REAR LID LOCK CYLINDER UNLOCK BUTTON REAR LID ALARM SWITCH, REAR LID CENTRAL LOCKING SYSTEM BUTTON REAR LID CONTROL MODULE 2 (IN REAR LID REAR LID REMOTE RELEASE BUTTON, FUEL FILLER DOOR RELEASE BUTTON RED WIRE RED/GRN WIRE RED/YEL WIRE TRUNK LID ALARM SWITCH, REAR LID CENTRAL LOCKING SYSTEM MOTOR VIO WIRE VIO/BLU WIRE VIO/RED WIRE W/ ELECTRONIC REAR LID OPENER W/O ELECTRONIC REAR LID OPENER WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE
