Audi Q7 4L facelift (2009-2015) control module (battery negative post) wiring diagram
This page shows the only wiring diagram for the component.control module (battery negative post), which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
control module (battery negative post) wiring diagram (1 of 1)
3.0L TURBO DIESEL
ACCESS/START AUTHORIZATION BUTTON (CENTER CONSOLE, RIGHT SIDE OF STEERING WHEEL)
ACCESS/START CONTROL MODULE (INTEGRAL TO STEERING COLUMN LOCK ACTUATOR)
BATTERY
BATTERY INTERRUPT IGNITER
BATTERY JUMP START TERMINAL
BATTERY MONITORING
BLK WIRE
BLK/BLU WIRE
BLU WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
CONTROL MODULE (BATTERY NEGATIVE POST)
ENGINE CONTROL MODULE (ECM) (RIGHT REAR OF ENGINE COMPT)
FUSE
FUSE PANEL D (BELOW DRIVER SEAT)
GENERATOR, VOLTAGE REGULATOR
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RELAY & FUSE PANEL E-BOX
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SOLID STATE
STARTER
STARTER RELAY
STARTER RELAY 2
SUPPLEMENTAL RESTRAINTS SYSTEM
TERMINAL 15 POWER SUPPLY RELAY (DRIVER'S SEAT RELAY & FUSE PANEL)
TIPTRONIC SWITCH
VIO/BLK WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Starting circuit -> CONTROL MODULE (BATTERY NEGATIVE POST)
