Audi Q7 4L facelift (2009-2015) combustion air blower Wiring diagram
This page shows the only wiring diagram for the component.combustion air blower, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combustion air blower (1 of 1)
ANTENNA AMPLIFIER 2
AUXILIARY HEATER CONTROL MODULE (IN LEFT FRONT WHEEL HOUSING)
AUXILIARY HEATER RF RECEIVER (RIGHT SIDE OF LUGGAGE COMPT)
BLK WIRE
BRN WIRE
COMBUSTION AIR BLOWER
COMPUTER DATA LINES SYSTEM
ENGINE COOLANT (EC) SWITCH-OFF VALVE (HEATER) (IF EQUIPPED)
FUSE CARRIER 1 FUSE 5
FUSE CARRIER 1 FUSE 8
FUSE PANEL B (LEFT INSTRUMENT PANEL)
FUSE PANEL F (RIGHT SIDE LUGGAGE COMPT)
GLOW PLUG (W/ FLAME MONITORING)
HEATER OVERHEAT FUSE
HOT AT ALL TIMES
METERING PUMP
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/VIO WIRE
TEMPERATURE SENSOR
WHT/GRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component: -> Auxiliary heater circuit -> COMBUSTION AIR BLOWER
