Audi Q7 4L facelift (2009-2015) camshaft adjustment valve 1 Wiring diagram
This page shows the only wiring diagram for the component.camshaft adjustment valve 1, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camshaft adjustment valve 1 (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CAMSHAFT ADJUSTMENT VALVE 1
CHARGE AIR COOLING PUMP
COOLANT FAN CONTROL MODULE
COOLANT FAN CONTROL MODULE 2
CRANKCASE VENTILATION SHUT-OFF VALVE
ENGINE COMPONENT POWER SUPPLY RELAY
ENGINE CONTROL MODULE (ECM)
FROM BATTERY JUMP START TERMINAL (DIAGRAM 1 OF 7)
FROM RELAY & FUSE PANEL E-BOX (DIAGRAM 1 OF 7)
FROM RELAY & FUSE PANEL E-BOX (DIAGRAM 4 OF 7)
FUEL METERING VALVE
FUSE 10
FUSE 13
FUSE 14
FUSE 15
FUSE 9 FUSE 8
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR 1
HEATED OXYGEN SENSOR 2
HEATER
HEATER 2
HIGH PRESSURE SENSOR
INTAKE MANIFOLD RUNNER CONTROL (IMRC) VALVE
LEAK DETECTION PUMP (LDP)
NCA WIRE
OIL PRESSURE REGULATION VALVE
OXYGEN SENSOR
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RELAY & FUSE PANEL E-BOX (LEFT SIDE OF PLENUM CHAMBER)
SECONDARY AIR INJECTION (AIR) SOLENOID VALVE
TO RELAY & FUSE PANEL E-BOX (DIAGRAM 4 OF 7)
WHT WIRE
YEL WIRE
Go to component: -> 3.0l sc, power distribution circuit (4 of 7) -> CAMSHAFT ADJUSTMENT VALVE 1
