Audi Q7 4L facelift (2009-2015) blu red/ Wiring diagram
This page shows the only wiring diagram for the component.blu red/, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blu red/ (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU RED/ WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRAKE LIGHT DISABLE RELAY
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAMSHAFT ADJUSTMENT VALVE 1 (REAR OF RIGHT CYLINDER HEAD)
CAMSHAFT ADJUSTMENT VALVE 2 (REAR OF LEFT CYLINDER HEAD)
CHARGE AIR COOLING PUMP
CLIMATRONIC CONTROL MODULE (IN UPPER CENTER CONSOLE)
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE REGULATOR VALVE
GRN RED/ WIRE
GRN VIO/ WIRE
GRN WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/VIO WIRE
HIGH PRESSURE SENSOR (EVAPORATOR EXPANSION VALVE, UNDER RIGHT SIDE OF DASH)
INTAKE MANIFOLD RUNNER CONTROL (IMRC) VALVE
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY & FUSE CARRIER (CENTER INSTRUMENT PANEL)
SECONDARY AIR INJECTION (AIR) SOLENOID VALVE
VIO/GRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component: -> Wiring diagram engine performance 3.0l sc (2 of 7) -> BLU RED/ WIRE
