Audi Q7 4L facelift (2009-2015) basic comfort Wiring diagram
This page shows the only wiring diagram for the component.basic comfort, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram basic comfort (1 of 1)
AFTER-RUN COOLANT PUMP
BASIC COMFORT
BLK WIRE
BRN WIRE
COOLING OIL VALVE
FRESH POWER SUNROOF CONTROL MODULE
FRONT PASSENGER'S CONTROL LOCKING UNIT
FRONT PASSENGER'S DOOR CONTROL MODULE
FRONT PASSENGER'S SIDE AIR BAG IGNITERS 1, 2
GLOVE COMPARTMENT RIGHT LAMP FOOTWELL SWITCH LAMP
GLOVE COMPARTMENT UNLOCK MOTOR
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
IGNITION COIL 4 W/ POWER OUTPUT STAGE
IGNITION COIL 5 W/ POWER OUTPUT STAGE
IGNITION COIL 6 W/ POWER OUTPUT STAGE
LEFT WASHER NOZZLE HEATER
LEVEL CONTROL SYSTEM COMPRESSOR MOTOR
METERING PUMP
MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH
NCA WIRE
PARTICULATE SENSOR
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA
RADIO, TELEPHONE, NAVIGATION SYSTEM ANTENNA SHIELD
REAR SLIDING SUNROOF CONTROL MODULE
RED WIRE
RIGHT AIR BLOWER WASHER CONTROL NOZZLE MODULE HEATER
RIGHT REAR BRAKE PAD WEAR SENSOR
RIGHT REAR FOOTWELL LAMP
ROOF BLIND CONTROL MODULE
TELEPHONE TRANSCEIVER
TRANSMISSION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE 2
W/ LEVEL CONTROL SYSTEM W/O LEVEL CONTROL SYSTEM
Go to component: -> Ground distribution circuit (1 of 7) -> BASIC COMFORT
