Audi Q7 4L facelift (2009-2015) backup switch Wiring diagram
This page shows the only wiring diagram for the component.backup switch, which is found in the car Audi Q7 4L facelift (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup switch (1 of 1)
AUTOMATIC DIMMING INTERIOR REARVIEW MIRROR (IF EQUIPPED)
AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE (BEHIND REARVIEW MIRROR)
BACKUP
BACKUP SWITCH
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
COMFORT SYSTEM CENTRAL CONTROL MODULE 2 (RIGHT SIDE OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
FUSE 7
FUSE 8
FUSE CARRIER 1 FUSE 6
FUSE CARRIER 2
FUSE PANEL C (RIGHT REAR ENGINE COMPT)
FUSE PANEL F (RIGHT SIDE LUGGAGE COMPT)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY (TERMINAL 15) RELAY ENERGIZED
LEFT TAILLAMP ASSEMBLY
MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT TAILLAMP ASSEMBLY
W/O HIGH BEAM ASSISTANCE
Go to component: -> Backup lamps circuit -> BACKUP SWITCH
