Audi Q5 II facelift (2020-2024) A/t circuit

AUTOMATIC TRANSMISSION CONTROL MODULE FUSE AUTOMATIC TRANSMISSION COUPLING POINT AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4 BLK/VIO WIRE BLU/GRY WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVE POSITION SENSOR DUAL-CLUTCH TRANSMISSION MECHATRONIC EARLY PRODUCTION ENGINE/MOTOR CONTROL MODULE FUSE 4 FUSE 6 FUSE PANEL 2 FUSE PANEL 5 FUSE PANEL B GEAR POSITION DISTANCE SENSOR 1 GEAR POSITION DISTANCE SENSOR 2 GEAR POSITION DISTANCE SENSOR 3 GEAR POSITION DISTANCE SENSOR 4 GRN WIRE HOT AT ALL TIMES HYDRAULIC PRESSURE SENSOR 1 HYDRAULIC PRESSURE SENSOR 2 LATE PRODUCTION PNK WIRE RED WIRE RED/VIO WIRE RELAY & FUSE PANEL 1 RELAY & FUSE PANEL 2 SOLENOID VALVE 1 SOLENOID VALVE 2 SOLENOID VALVE 3 SOLENOID VALVE 4 SOLENOID VALVE 5 SOLENOID VALVE 6 SUPPLEMENTAL RESTRAINTS SYSTEM TEMPERATURE SENSOR (IN CONTROL MODULE) TRANSMISSION CONTROL MODULE TRANSMISSION ELECTRIC PUMP 2 TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP ROTOR POSITION TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION INPUT SPEED SENSOR 1 TRANSMISSION INPUT SPEED SENSOR 2 WHT WIRE WHT/YEL WIRE

4-PIN CONNECTOR AUTOMATIC TRANSMISSION COUPLING POINT BRN WIRE COMPUTER DATA LINES SYSTEM D/S EARLY PRODUCTION FUSE 12 FUSE PANEL C GRN WIRE GRY/BLK WIRE GRY/BRN WIRE HOT AT ALL TIMES LATE PRODUCTION LEFT MULTI-FUNCTION BUTTONS MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/BRN WIRE ORG/VIO WIRE PARKING LOCK BUTTON PARKING LOCK INDICATOR LAMP PARKING LOCK SOLENOID PNK WIRE RED WIRE RED/VIO WIRE RIGHT MULTI-FUNCTION BUTTONS SEATS SYSTEM SELECTOR LEVER SELECTOR LEVER POSITION SENSOR SELECTOR LEVER RELEASE BUTTON SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER TRANSMISSION RANGE DISPLAY SHIFT LOCK SOLENOID SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL HEATING BUTTON STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON TRANSVERSE SELECTOR LEVER LOCK MOTOR TRANSVERSE SELECTOR LEVER LOCK SENSOR VIO WIRE W/ STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE W/O STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
